SL Multi Soundbar

€0.00

Left, Centre, Right Loudspeaker

The SL Multi Soundbar can be used as a single LCR loudspeaker, or for more powerful systems, used as a single mono centre channel. The standard sizes are designed to compliment today’s flat screens. Bespoke width options are also available.

Artcoustic pioneered the first concept of an all-in-one LCR (left, centre and right) soundbar as far back as 1997. The SL version is an evolution of this classic loudspeaker and is available in six standard versions, with the option to go bespoke. All feature clean, discrete aesthetics with high output timbre-matched performance.

All SL Multi Soundbars are VESA compatible.
Our SL Multi Soundbar is available in six standard sizes – see below for specification details.

Left, Centre, Right Loudspeaker

The SL Multi Soundbar can be used as a single LCR loudspeaker, or for more powerful systems, used as a single mono centre channel. The standard sizes are designed to compliment today’s flat screens. Bespoke width options are also available.

Artcoustic pioneered the first concept of an all-in-one LCR (left, centre and right) soundbar as far back as 1997. The SL version is an evolution of this classic loudspeaker and is available in six standard versions, with the option to go bespoke. All feature clean, discrete aesthetics with high output timbre-matched performance.

All SL Multi Soundbars are VESA compatible.
Our SL Multi Soundbar is available in six standard sizes – see below for specification details.




Specifications

  • SL Multi Soundbar S 1094 (per channel)
    Frequency range 80 Hz – 40 kHz
    Usable LF response 77 Hz -6db
    Coverage window 90 - 90
    Rated impedance 12 Ohms
    Sensitivity @ 1 watt 96 dB
    Power handling 60 W @ 22 Vrms
    Maximum continuous SPL @ 1 meter 108 dB
    Power draw 7 W 7 Vrms
    Maximum acoustic peak SPL crest factor 6 @ 1 meter 114 dB
    Transducers FR – 3” woofer (x 2) HF 1.5” (x 1)
    Enclosure Medium density Fiber board
    Weight: 5.5 kg
    Dimensions: H: 100 W: 1094 D: 70/80 mm


    SL Multi Soundbar M 1222 (per channel)
    Frequency range 80 Hz – 40 kHz
    Usable LF response 77 Hz -6db
    Coverage window 90 - 90
    Rated impedance 12 Ohms
    Sensitivity @ 1 watt 96 dB
    Power handling 60 W @ 22 Vrms
    Maximum continuous SPL @ 1 meter 108 dB
    Power draw 7 W 7 Vrms
    Maximum acoustic peak SPL crest factor 6 @ 1 meter 114 dB
    Transducers FR – 3” woofer (x 2) HF 1.5” (x 1)
    Enclosure Medium density Fiber board
    Weight: 6.5 kg
    Dimensions: H: 100 W: 1222 D: 70/80 mm


    SL Multi Soundbar L 1441 (per channel)
    Frequency range 80 Hz – 40 kHz
    Usable LF response 77 Hz -6db
    Coverage window 90 - 90
    Rated impedance 12 Ohms
    Sensitivity @ 1 watt 96 dB
    Power handling 60 W @ 22 Vrms
    Maximum continuous SPL @ 1 meter 108 dB
    Power draw 7 W 7 Vrms
    Maximum acoustic peak SPL crest factor 6 @ 1 meter 114 dB
    Transducers FR – 3” woofer (x 2) HF 1.5” (x 1)
    Enclosure Medium density Fiber board
    Weight: 8.5 kg
    Dimensions: H: 100 W: 1441 D: 70/80 mm

    SL Multi Soundbar XL 1711 (per channel)
    Frequency range 80 Hz – 40 kHz
    Usable LF response 77 Hz -6db
    Coverage window 90 - 90
    Rated impedance 12 Ohms
    Sensitivity @ 1 watt 96 dB
    Power handling 60 W @ 22 Vrms
    Maximum continuous SPL @ 1 meter 108 dB
    Power draw 7 W 7 Vrms
    Maximum acoustic peak SPL crest factor 6 @ 1 meter 114 dB
    Transducers FR – 3” woofer (x 2) HF 1.5” (x 1)
    Enclosure Medium density Fiber board
    Weight: 11.5 kg
    Dimensions: H: 100 W: 1711 D: 70/80 mm

    SL Multi Soundbar XXL 1904 (per channel)
    Frequency range 80 Hz – 40 kHz
    Usable LF response 77 Hz -6db
    Coverage window 90 - 90
    Rated impedance 12 Ohms
    Sensitivity @ 1 watt 96 dB
    Power handling 60 W @ 22 Vrms
    Maximum continuous SPL @ 1 meter 108 dB
    Power draw 7 W 7 Vrms
    Maximum acoustic peak SPL crest factor 6 @ 1 meter 114 dB
    Transducers FR – 3” woofer (x 2) HF 1.5” (x 1)
    Enclosure Medium density Fiber board
    Weight: 11.5 kg
    Dimensions: H: 100 W: 1904 D: 70/80 mm

    SL Multi Soundbar XXXL 2230 (per channel)
    Frequency range 80 Hz – 40 kHz
    Usable LF response 77 Hz -6db
    Coverage window 90 - 90
    Rated impedance 12 Ohms
    Sensitivity @ 1 watt 96 dB
    Power handling 60 W @ 22 Vrms
    Maximum continuous SPL @ 1 meter 108 dB
    Power draw 7 W 7 Vrms
    Maximum acoustic peak SPL crest factor 6 @ 1 meter 114 dB
    Transducers FR – 3” woofer (x 2) HF 1.5” (x 1)
    Enclosure Medium density Fiber board
    Weight: 11.5 kg
    Dimensions: H: 100 W: 2230 D: 70/80 mm

    NB: Please download the user manual for the full specification.

  • Colour:

    Cabinet: RAL/NCS, SL Satin
    Screen: RAL/NCS

    Standard cabinet/screen colours are black/white

    Finish:

  • 2D / 3D Files
    User Manual
    Images
    Product Sheet

Get in touch


Projects featuring SL Multi Soundbar

About SOUNDBars

Artcoustic pioneered the first concept of an all-in-one LCR (left, centre and right) soundbar as far back as 1997. The SL version is an evolution of this classic loudspeaker and is available in four standard versions, with the option to go bespoke. All feature clean, discrete aesthetics with high output timbre-matched performance.
