SL Architect F-1

€0.00

In-Ceiling Loudspeaker

The SL Architect F-1 is a full-range single-source speaker, targeting multi-room applications.

The SL Architect F-1 performs with an equally impressive dynamic range within a residential solution, or in a professional setup, such as a bar, restaurant, hotel, or simply anywhere, where the typical Artcoustic superior quality sound reproduction is expected, all without the need of a subwoofer.

The SL Architect F-1 has an impressive operating range starting at 40 Hz (-3dB) and extending to an upper frequency response of 40 kHz.

The SL Architect F-1 is a true all-rounder, fitting a large portfolio of applications.

In-Ceiling Loudspeaker

The SL Architect F-1 is a full-range single-source speaker, targeting multi-room applications.

The SL Architect F-1 performs with an equally impressive dynamic range within a residential solution, or in a professional setup, such as a bar, restaurant, hotel, or simply anywhere, where the typical Artcoustic superior quality sound reproduction is expected, all without the need of a subwoofer.

The SL Architect F-1 has an impressive operating range starting at 40 Hz (-3dB) and extending to an upper frequency response of 40 kHz.

The SL Architect F-1 is a true all-rounder, fitting a large portfolio of applications.




Specifications

  • Frequency range 50 Hz – 40 kHz
    Usable LF response 40 Hz -6db
    Coverage window 90 - 90
    Rated impedance 8 Ohms
    Sensitivity @ 1 watt 92 dB
    Power handling 100 W
    Maximum continuous SPL @ 1 meter 109 dB
    Maximum acoustic peak SPL crest factor 6 @ 1 meter 115 dB
    Transducers LF – 5.5” woofer (x 1) HF 1.5” (x 1)
    Enclosure Medium density Fiber board
    Weight: 3.5 kg
    Dimensions (mm): H 300 • W 300 • D 86

    NB: Please download the user manual for the full specification.

  • Colour:

    Cabinet: RAL/NCS, SL Satin
    Screen: RAL/NCS

    Standard cabinet/screen colours are black/white

    Finish:

  • 2D / 3D Files
    User Manual
    Product Sheet
    Images

Get in touch


Projects featuring SL Architect F-1

About Architect Series

The Architect in-ceiling loudspeakers have been designed and engineered with the same high specifications as all the other Artcoustic models. These loudspeakers have been created to deliver Artcoustic performance from an ultra-thin design, with a clean contemporary aesthetic, but allowing the flexibility to install in-ceiling or in-wall.
