Specifications
-
Frequency range 25 Hz – 170 Hz
Usable LF response 22 Hz -6dB
Coverage window Omni
Rated impedance 8 Ohms
Sensitivity @ 1 watt 97 dB
Power handling 700 W @ 75 Vrms
Maximum continuous SPL @ 1 meter 125 dB Power draw 630 W 71 Vrms
Maximum continuous SPL @ 1 meter @ 30 Hz 122 dB
Maximum acoustic peak SPL crest factor 6 @ 1 meter 131 dB
Transducers LF – 12” woofer (x 2)
Enclosure Medium density Fiber boardAmplification CPH-1000D bridged
Weight: 38.2 kg
Dimensions: H: 600 W: 600 D: 255 mmNB: Please download the user manual for the full specification.
-
Colour:
Cabinet: RAL/NCS, SL Satin
Standard cabinet colours are black/white -
About Subwoofer Series
More than 20 years of subwoofer technology and acoustic evolution has developed into the most advanced and powerful subwoofer series ever produced by Artcoustic.
The Artcoustic Sub Series is a low resonance frequency 4th order band pass design, which ensures powerful and clean bass. Ideal for professional applications such as recording and film studios, dedicated cinemas and fixed installations.
The Artcoustic SL Architect Sub 1 delivers clean, musical bass from a compact architectural design, ideal for luxury residential and commercial installations. Employing a single 5.5-inch low-frequency transducer and infinite-baffle architecture, it uses the installation cavity as the rear acoustic volume, removing the need for a conventional enclosed subwoofer cabinet.
With usable low-frequency extension down to 35 Hz (-6 dB) and an installation depth of just 86 mm, the SL Architect Sub 1 integrates discreetly into ceilings, walls and custom joinery. Available in black, white or specified RAL/NCS colours, it is ideal for installations where sound quality and interior design are equally important.
